Technical Specification
-
Tank body
-
Galvanized tank; optional plastic tank available upon customer request
-
Upper hatch 500 mm with ladder
-
Rear hatch 700 mm
-
3 baffles inside the tank
-
Fill level indicator
-
2 work halogen lights
-
Rear rotary flange with pneumatic slide valve for filling
-
8” rubber cup with pneumatic slide valve at the top of the tank for emptying
-
6” vent valve
-
6” suction hose, 6 m long
-
Three-axle chassis
-
Galvanized chassis frame
-
Dual-circuit brakes with ABS system
-
BPW axles with pneumatic suspension
-
Liftable front axle
-
Tires 385/55 R 22.5
-
Two-speed support leg
-
2 aluminum hose trays for 6 m hoses
-
Maximum speed 100 km/h
NOTE
-
The transporter can be equipped with a rotary pump or compressor for independent filling and emptying
-
Possibility to fit chassis from various manufacturers or chassis supplied by the customer
-
