Standard Equipment
-
Tank
-
Double-sided hot-dip galvanized tank
-
Tank passivation protecting fresh galvanizing against the effects of slurry
-
Rear manhole Ø500 mm (in T507/2), Ø700 mm (in T507/1, T507/2, T507/6) – hinged cover
-
Tubular filling level indicator with sight glass
-
Drain outlet with 1½” valve – located at the lowest point of the tank
-
4” sight glass on the rear tank bottom plate
Tanker construction: self-supporting
-
SELF-SUPPORTING – drawbar mounted on reinforced supports under the tank, hot-dip galvanized
-
Replaceable coupling – screwed, Ø50 mm
-
Mechanically adjustable support leg
-
Single-axle wheelset, two wheels
-
Tires according to the table
-
Mudguards
-
Pneumatic dual-circuit brake system with 4-level brake force adjustment
-
Manual parking brake
-
Compressor – type according to the table
-
PTO drive at 540 rpm or 1000 rpm – optional
-
Reinforced temperature-resistant hoses connecting the fittings
-
Overfill protection via two-ball valve with sight glass at the top of the tank and siphon with sight glass
-
Pressure/vacuum gauge
-
Two safety valves: overpressure up to 0.05 MPa and vacuum up to -0.05 MPa
-
Oil separator – wet air filter, silencer to reduce compressor noise
-
Suction nozzles 4” Ø110 mm (in T507/6 – 6” Ø150 mm)
-
Main drain nozzle in the rear manhole cover 4” – with 4” hydraulic gate valve
-
Front left and right nozzles – sealed, prepared for manual gate valve installation
-
Rear nozzle – sealed, prepared for manual gate valve installation
-
12V electrical and lighting installation
-
4” hose (Ø110)
-
Transport handles for suction hose
-
Suction hose with basket – protects against intake of large debris
-
Suction hose length – 6 m
Spreading device
-
Profiled spreading spoon, POMOT 94 pattern, spreading width up to 14 m
Homologation certificate
-
Enables registration and operation on public roads
Power Take-Off Shaft (PTO)
Version Suspension Tire Dimensions Tires Compressor Type SELF-SUPPORTING ECONOMIC single-axle 745×255 10.0/75-15.3 STANDARD single-axle 855×290 11.5/80-15.3 CLASIC single-axle 855×290 11.5/80-15.3 PREMIUM single-axle 890×400 400/60-15.5 -
