Slurry Tanker T530 – 30 000 Liters

TRIDEM suspension (two steering axles) or hydraulic TRIDEM suspension

The largest tanker in our offer, designed with demanding users in mind. Despite its size, the tanker is efficient and ensures user safety while maintaining low operating costs.


📱 Marcin Górski: +48 691 897 575 | 📧 m.gorski@pomot.pl

📱 Łukasz Lechicki: +48 607 999 359 | 📧 l.lechicki@pomot.pl

Category: Tag:

Standard Equipment

  1. Tank

    • Tank hot-dip galvanized on both sides

    • Tank passivation protecting fresh galvanization from slurry corrosion

    • Rear hatch ø700mm – hatch cover hinged

    • Tubular filling level indicator with sight glass

    • Drain outlet with 1 ½” valve – at the lowest point of the tank

    • Sight glass 4” on the rear bottom plate

    • Upper hatch ø350mm

    • Safety valve 4”

    • 8” nozzle on top of the tank, plugged – prepared for mounting a rubber filling funnel

    Trailer construction: frame type

    • FRAME TYPE – tank mounted on a frame made of closed section steel profile

    • Replaceable hitch – bolted ø50mm

    • Mechanically adjustable support leg

    • Wheelset: Tridem or hydraulic Tridem

    • Tires according to table

    • Mudguards

    • Pneumatic dual-circuit brake system with 4-stage brake force regulation

    • Parking handbrake

    • Compressor – type according to table

    • Power take-off speed 540 rpm or 1000 rpm – optional

    • Reinforced, temperature-resistant hoses connecting the fittings

    • Overfill protection via a two-ball valve with sight glass on top of the tank and a siphon with sight glass

    • Pressure gauge with manometer

    • Two safety valves: overpressure up to 0.05 MPa and underpressure up to -0.05 MPa

    • Oil separator – wet air filter, muffler silencing compressor operation

    • Suction nozzles 6” ø150mm

    • Main drain nozzle in the rear hatch cover 6” – with hydraulic gate valve 6”

    • Front left and right nozzles – plugged, prepared for manual gate valve installation

    • Rear nozzle – plugged, prepared for manual gate valve installation

    • Electrical installation 12V and lighting

    • Hose 6” (ø150)

    • Transport handles for suction hose

    • Hose with suction basket – protecting against suction of large objects

    • Suction hose length – 6m

    Spreading device

    • Profiled spreading shovel, POMOT 94 model, spreading width up to 14m


    Power Take-Off Shaft (PTO)

    Version Suspension Tire Dimensions Tires Compressor Type
    ECONOMIC TRIDEM (including 2 steering axles) 1244×543 560/60R22.5 MEC 11000 or KD 12000
    STANDARD TRIDEM (including 2 steering axles) 1270×700 700/50×22.5 MEC 11000 or KD 12000
    CLASSIC TRIDEM (including 2 steering axles) 1340×600 600/55×26.5 MEC 11000 or KD 12000
    PREMIUM TRIDEM (including 2 steering axles) 1340×700 700/50×26.5 MEC 13500 or KD 12000
    ECONOMIC HYDRAULIC TRIDEM 1244×543 560/60R22.5 MEC 11000 or KD 12000
    STANDARD HYDRAULIC TRIDEM 1270×700 700/50×22.5 MEC 11000 or KD 12000
    CLASSIC HYDRAULIC TRIDEM 1340×600 600/55×26.5 MEC 11000 or KD 12000
    PREMIUM HYDRAULIC TRIDEM 1340×700 700/50×26.5 MEC 13500 or KD 12000

Optional Equipment

Spreading Devices

  • Wide-angle spreader (working width up to 14 m)

  • Slurry thrower (working width from 6 to 15 m)

  • Mobile device for road watering and crop irrigation with 2.5 m width

  • Mobile device for road watering and crop irrigation with 4.5 m width

  • PERROT type spreading shovel (working width up to 12 m)

  • Double spreading shovel (working width up to 16 m)

  • Surface injection unit with trailing hose system, working width 3 m, POMOT brand – mechanically foldable

  • Surface injection unit with trailing hose system, working width 3 m, POMOT brand – hydraulically foldable

  • Plant watering device

Chassis

  • Upper transport hitch (only for frame construction)

  • Longitudinal leaf spring drawbar

  • K80 ball hitch

  • Rear steering axle (only for type T 546)

  • Hydraulic support leg

  • Hydraulic brake (for one axle)

  • Wheel chocks (2 pcs.)

Filling Systems

  • Additional manual gate valve 6″

  • Quick coupling for manual gate valve 6″

  • Suction hose extension 6″, length 3 m

  • Suction hose extension 6″, length 6 m

  • Additional suction hose 6”, length 6 m

  • Injector 4″ or 6″ – suction from depth up to 10 m

  • Hydraulic compressor drive

Accessories

  • Galvanized metal hose boxes (2 pcs.)

  • Galvanized metal boxes for transporting crop protection agents (2 pcs.)

  • Calibration stickers for pipe level indicator

  • Fully openable rear bottom plate

  • Upper hatch Ø500 mm with ladder

  • Ladder

  • W52 fitting with 2″ ball valve

  • Pneumatic agitator

  • Hydraulic screw agitator

  • Wide-angle power take-off shaft

  • Plastic toolbox

  • Handwashing dispenser

  • Additional painting of galvanized tank (one side)

  • Additional painting of galvanized frame

NOTE: Other additional equipment options are also available (see the “Sewer Trucks Accessories” section).
