Description
Vacuum-Pressure Combination Unit on Mitsubishi Fuso Canter Chassis
The unit is mounted on a Mitsubishi Fuso Canter chassis. The sludge tank capacity is approximately 3,200 liters, with an additional water chamber of about 1,000 liters. It is equipped with an air-cooled JUROP compressor delivering approx. 440 m³/h.
One of the key advantages of this vehicle is the ability to convert the entire tank into a water chamber thanks to a special connection between the sludge and water tanks.
The high-pressure hose reel, driven hydraulically and equipped with a 60 m DN 16 hose, can rotate 90° to the left and right, significantly easing operation.
Combined with a high-pressure pump with an output of approx. 93 L/min at 170 bar, the unit makes sewer cleaning more efficient and convenient.
The vacuum pump (compressor) and high-pressure pump can operate simultaneously, which greatly expands the vehicle’s functionality.
Control is available through two panels mounted at the rear of the vehicle, as well as via radio remote control.
