Technical Specification
| Parameters | Description |
|---|---|
| Material | – structural carbon steel S355
– wear-resistant carbon steel S500 – acid-resistant steel |
| Tank capacity | from 6000 liters up to 20000 liters |
| Suction system | from 600 m³/h |
| Small water system option | 120 l/min, 160 bar |
| Suction arm option variant I | 4500 mm, rotation angle 270°, lifting 27°, tilt 25° |
| Suction arm option variant II | 5500 mm, rotation angle 270°, lifting 59°, tilt 12° |
| Hydraulic hose reel option | hydraulic hose reel for suction hose |
| Control | manual and remote control |
| Tank emptying | via sliding piston, tipping, or gravity |
| Sludge pump | optional installation of sludge pump |
| Anti-corrosion protection | hot-dip galvanizing of the tank and intermediate frame |
